Effekta Online-USV, 40000VA, 7min, PTX3/3, Quasar Q040-07
Effekta Online-USV, 40000VA, 7min, PTX3/3, Quasar Q040-07
incl.PowerShut+cable input/output (3/3-phase 400VA), Quasar, RS-232 interface, ***Dual converter*** 2 year warranty, LED/LCD display,
approx. 32000 watts, 128x batteries 12V/9.5,
Technical data:
UPS classification: Online double conversion (VFI-SS-111) according to IEC 62040
Input voltage: 3 x 400 VAC ± 20%
Input current: 57.8 A at 400 V with rated load
Input frequency: 50 or 60 Hz ± 20%
Power factor: > 0.95
Rectifier: 6-pulse (12-pulse optional)
Output power: 40 kVA / 32 kW
Output voltage: 3 x 400 VAC ± 1%
Output frequency: 50 or 60Hz (+/-1...+/-4)% adjustable
Overload capacity: 125% for 10min, 150% for 10s
Short circuit current: 300% for < 3s
Distortion factor: < 3% with linear load, < 5% with non-linear load
Efficiency: > 92% (without load)
Power loss: 2.7 kW at rated load, without load
Charging current: max. 7 A, IU charging with soft start
Charging voltage: 432 V real (2.25V/cell, adjustable)
Autonomy time: 7 min at nominal active load, extendable
Batteries: maintenance-free lead-acid batteries 384V/38Ah,
with five years expected service life
Battery type: 128 x EFFEKTA BT12-9.5
Protection class IP20
Colour RAL 7035
Working temperature 0?40°C, recommended +25°C
Dimensions UPS: 1220x530x950 (HxWxD in mm), 565 kg
Furnishing:
Electronic bypass
Manual service bypass
LCD display
RS232 and contact interface
Lan-Powershut shutdown and management software for all current operating systems (incl. RS232 cable)
