Effekta Online-USV,30000VA, 12min, Triton 3/3,

*Order-related, non-cancellable*, UPS Triton 30 kVA, online continuous. 12 min., 3/3-phase, black, modular design with 1 module each 30kVA/27kW RS232, RS485 IGBT rectifier LAN powershut+M2505 cable with the following specifications: UPS classification: Online double converter (VFI-SS-111) according to IEC 62040-3 Rectifier: IGBT rectifier bridge Input power factor: 0.99 Mains harmonics: <3% THD (current) Input voltage: 3 x 380/400/415 VAC +15% / -45% Input frequency: 50 / 60 Hz, +15% / -20% Inverter: IGBT inverter Output power: 30 kVA / 27 kW Output voltage: 3 x 380/400/415 VAC, adjustable Output frequency: 50 Hz ± 1% Overload capacity: up to 125% for 10 min., 125% for 10 min., 150% for 1 min. Nominal output current at 400 V: 39 A Short circuit current: 99 A (200 ms) Crest factor: 3:1 Static bypass: Electronic thyristor switch, uninterruptible Overload capacity: 150% continuous, 1000% for 20ms Batteries: 432V/33Ah, maintenance-free lead-fleece batteries with 10-year service life expectancy Battery type: 36 pieces EFFEKTA BTL12-33 Charging current: max. 10 A Autonomy time: 12 minutes at nominal load and cos phi 0.8 General: Dimensions UPS: 1600 x 600 x 780 (HxWxD in mm) Weight UPS: 198 kg Weight UPS including internal batteries: 570 kg Working temperature: 0 - 40°C, battery max. 20° C Heat loss: 1150 W Cooling air flow: 643 cbm/h Noise level: max. 55dB(A) Protection class: IP20 Color: RAL 9004 Radio interference suppression: according to DIN EN 62040-2, class C3 Performance features: easy to maintain thanks to modular design, thus very low MTTR value IGBT rectifier very large input voltage window electronic bypass, manual service bypass extensive communication interfaces (2 x RS232, 2 x RS485, EPO, 2 x slot for relay card or SNMP, parallel port)
