Supported light types - incandescent and halogen lamps 1-220W, dimmable LED 50-200VA/1W - 200W, resistive-inductive loads ferromagnetic transformers 50-150VA
Shelly Dimmer2 is a smart light intensity control switch unit with precise power measurement that fits into all electrical installations. It offers a full set of dimming functions and can even be used in homes where the neutral wire is missing. Use it to control, dim and measure the power of a wide range of halogen lights, dimmable LEDs and ferromagnetic transformers between 110 and 230 V ± 10%.
WLAN operated
Connect Shelly 1 to your WiFi network. No HUB required!
No neutral wire required
Shelly Dimmer2 does not require a neutral wire to provide all dimming functions.
Energy monitoring
Shelly Dimmer2 offers precise monitoring of power consumption.
Adjusting the light intensity
Use the dimming function to adjust the brightness of your lighting according to your needs.
Smart schedules
Set custom schedules based on your daily routine or control your lights based on sunrise and sunset.
Intelligent scenarios
Set custom scenarios by combining Shelly Dimmer2 with your other Shelly devices.
Different light types and brightness levels are suitable depending on the activity and time of day. With Shelly Dimmer2 you can adjust the brightness according to your preferences and choose the perfect lighting level for reading bedtime stories, watching TV, eating dinner, etc. For further customization, the smart schedule function allows you to set a starting hour for each activity. As soon as the lights in the children's room are dimmed, the children know it is time for bed.
Don't lose the bright light at home when the weather is gloomy and rainy! Thanks to its LUX sensor, Shelly Door/Window2 can be set to follow the natural light outside, turning the lights on earlier on rainy days and slowly increasing the brightness as the afternoon turns to evening.
Create your own "movie scene" with Shelly and treat yourself to a real cinema experience. Set Shelly to turn on the projector, dim the lights and pull down the blinds. Now you can enjoy your favorite comedy, horror movie or thriller in comfort and privacy. For added convenience, you can pair Shelly with your favorite voice assistant and simply say: "Turn on the movie routine!"
Going to the bathroom at night is no longer a nuisance for your sleepy eyes. Shelly Dimmer2 has a "night mode" function that sets the brightness of the light to a low level during the night hours. Now, when the light is turned on manually, by voice or by a motion sensor, it is always dim and gentle.
Shelly devices are compatible with Alexa, Google Home, Android and iOS. Together with the voice assistant, you can control Shelly devices with your voice!
| ENERGY | |
|---|---|
| Power supply AC | 110 - 230 V ± 10 %, 50/60 Hz |
| channels | 1 channel |
| SPECIAL FEATURES | |
| Overheating protection | Yes |
| Overvoltage protection | Yes |
| Performance measurement | Yes |
| Dimming | Yes |
| Dimmable LED | 50 - 200 VA / 10 W - 200 W |
| Incandescent lamps and halogen light sources | 10 - 220W |
| Working without a neutral conductor | Yes |
| CHARACTERISTICS | |
| Color change | No |
| Predefined effects | Yes |
| operating temperatur | 0 °C to + 35 °C |
| Power consumption of the device | < 1W |
| Intelligent on/off | Yes |
| Local and remote control | Yes |
| Sunrise/sunset | Yes |
| Weekly plan | Yes |
| UL listed option | No |
| CONNECTIVITY | |
| Wireless | Yes |
| Wi-Fi protocol | 802.11 b/g/n |
| Wi-Fi radio frequency | 2412 - 2484MHz |
| Wi-Fi radio signal power | 1mW |
| WI-FI RANGE UP TO 50 M OUTDOORS AND UP TO 30 M INDOORS (DEPENDING ON BUILDING MATERIALS) | |
| DIMENSIONS | |
| Size | 42mm x 36mm x 14mm |
