Mini disc magnet Slimline for window/door contacts
Ultra thin disc magnet for all window/door contacts with a diameter of 15mm and a height of 2mm - self-adhesive. Adhesive force of approx. 1.7 kg!
Mini disc magnet Slimline for window/door contacts
Ultra thin disc magnet for all window/door contacts with a diameter of 15mm and a height of 2mm - self-adhesive. Adhesive force of approx. 1.7 kg!
The Slimeline magnet is glued and should be placed exactly opposite the marked area of the sensor, like the usual magnets supplied (see instructions).
Advantages:
- Space-saving
- better appearance
If ordered in conjunction with the window/door contacts, the magnet included in the standard delivery will still be included.
| material | NdFeB |
| shape | Disc self-adhesive |
| diameter | 15mm |
| Height | 2mm |
| tolerance | +/- 0.1mm |
| Magnetization direction | axial (parallel to height) |
| Coating | nickel-plated (Ni-Cu-Ni) |
| magnetization | N35 |
| Adhesive force | approx. 1.7 kg (approx. 16.7 N) |
| Displacement force | approx. 330 g (approx. 3.27 N) |
| max. operating temperature | 80°C (possibly lower) |
| adhesive | 3M, No. 4920, 0.40 mm |
| Durability of adhesive | 18 months (approx.) |
| Weight | 2.7g |
