Mean Well power supply - 48V 120W DIN rail, narrow
Mean Well power supply - 48V 120W DIN rail, narrow
Mean Well power supply - 48V 120W DIN rail, narrow
SDR-120-48
For DIN Rail, top hat rail
Input: 88~264VAC, 124~370VDC
Output: 2.5A, 48V DC, 120 Watt, adjustable from approx. 48V to 55V
Ambient temperature: -25°C~+70°C, ensure adequate ventilation.
LxWxH 40 x 125.2 x 113.5 mm
Protection marking: See meanwell.com
For further information please refer to the data sheet
Details about Mean Well power supply - 48V 120W DIN rail, narrow
Manufacurer:
SDR-120-48
Weight:
SDR-120-48
