Ubiquiti EdgeSwitch 24 / 24 Gigabit RJ45 Ports / 2 SFP Ports / 250W / PoE+ / ES-24-250W
Ubiquiti EdgeSwitch 24 / 24 Gigabit RJ45 Ports…
471.55
2.4 GHz, 25+ km connection range
450+ Mbps throughput
Improved mounting
Special spectral analysis radio
Technical specifications
| Mechanical | |
|---|---|
| Dimensions | 420 x 420 x 289 mm (16.5 x 16.5 x 11.4") |
| Weighing | 1.8 kg (4 pounds) |
| Housing material | UV-stabilized plastic, powder-coated SPCC |
| Wind survivability | 200 km/h (125 mph) |
| Wind load | 342.5 N at 200 km/h (77 lbf at 125 mph) |
| Mounting | Pole mounting kit (included) |
| hardware | |
| Network interface | (1) GbE RJ45 port |
| Power method | Passive PoE (pairs 4, 5+ 7, 8 return) |
| Max. Power consumption | 7,5 W |
| Power supply | 24 V, 0.5 A Gigabit PoE adapter (included in scope of delivery) |
| ESD/EMP protection | Air/contact: ± 24 kV |
| LEDs | Power, Ethernet, (4) signal strength |
| RoHS conformity | Yes |
| Salt spray test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
| Vibration test | IEC 68-2-6 |
| Thermal shock test | IEC 68-2-14 |
| UV test | IEC 68-2-5 at 40 °C (104 °F) Equivalent: ETS 300 019-1-4 |
| Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G Method 506.5 |
| Operating temperature | -40 to 70 °C (-40 to 158 °F) |
| Operating humidity | 5 to 95 % non-condensing |
| Certifications | CE, FCC, IC |
| system | |
| Gain | 18 dBi |
| Channel sizes PtP mode PtMP mode | 10/20/40 MHz 10/20/40 MHz |
| Operating frequency (MHz) | |
| Worldwide | 2412-2472 MHz |
| USA | 2412-2462 MHz |
| Management radio (MHz) | |
| Worldwide | 5150-5250 MHz |
| USA | U-NII-3: 5725-5850 MHz |
