Ubiquiti EdgeSwitch 24 / 24 Gigabit RJ45 Ports / 2 SFP Ports / 250W / PoE+ / ES-24-250W
Ubiquiti EdgeSwitch 24 / 24 Gigabit RJ45 Ports…
471.55
5 GHz, 10+ km connection range
450+ Mbps throughput
Isolated antenna design suppresses RF noise
Special spectral analysis radio
Technical specifications
| Mechanical | |
|---|---|
| Dimensions | Without horn: 131 x 131 x 65 mm (5.2 x 5.2 x 2.6") With horn: 174 x 174 x 150 mm (6.9 x 6.9 x 5.9") |
| Weight | Without horn: 408.2 g (0.9 lb) With horn: 725.7 g (1.6 lb) |
| Mounting | Mast mounting kit (included in scope of delivery) |
| Wind load | 36N at 200 km/h (8.09 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| hardware | |
| Network interface | (1) 10/100/1000 MbE port |
| Power method | Passive PoE (pairs 4, 5+ 7, 8 return) |
| Power supply | 24 V, 0.5 A Gigabit PoE adapter (included in scope of delivery) |
| Max. Power consumption | 8,5 W |
| Supported voltage range | 20-26 V direct current |
| LED | (1) Power |
| Operating temperature | -40 to 70 °C (-40 to 158 °F) |
| Operating humidity | 5 to 95 % non-condensing |
| Certifications | CE, FCC, IC |
| system | |
| Gain | 14 dBi |
| Beam width | 45° (standard horn) |
| Operating frequency (MHz) | |
| Worldwide | 5150-5875 MHz |
| USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 | 5150-5250 MHz 5250-5350 MHz 5240-5725 MHz 5725-5850 MHz |
| Management radio (MHz) | |
| Worldwide | 2412 - 2472 MHz |
| USA/California | 2412 - 2462 MHz |
Manufacurer:
Weight:
Storage:
