Poynting Antenna A-XPOL-001-V2-41 5G/LTE SMA (M) - White

Cross Polarized Omnidirectional LTE 5G Antenna XPOL-A0001-V2-41

overview

The XPOL-1-5G is Poynting's second generation "V2" of this highly popular cross-polarized (XPOL), cellular band, 2x2 MIMO antenna. A 4x4 MIMO variant is also available for custom requirements. The antenna has been completely redesigned from the previous generation and features a completely new housing and antenna design. The antenna now covers the newer 3400-3800 MHz bands as well as the sought-after lower 698 MHz band, previously unavailable from our V1, and is suitable for 2G, 3G, 4G, and 5G. This antenna performs excellently in the following frequency bands: 698 - 960 MHz, 1700 - 2170 MHz, 2300 - 2700 MHz & 3400 - 3800 MHz, with a peak gain of 4 dBi across the operating frequency bands.
The radiation pattern of this antenna is omnidirectional and exceptionally well-controlled, further enhancing its performance. This makes the antenna perfect for most applications, such as urban, rural, agricultural, and commercial areas, to achieve the best possible coverage over a wide area. The robust mechanical housing design makes the antenna weather-, dust-, and vandal-resistant, giving it an IP65 rating suitable for harsh environments.

Characteristics

• Exceptional performance across major 4G/5G bands
• New 3400 to 3800 MHz, 5G band
• Broadband, including the latest 3.5 GHz bands
• High gain for the antenna size
• Broadband 2X2 or 4X4 MIMO 4G/5G antenna
• Backward compatible 2G/3G/4G/LTE antenna (5G Ready)
• Weather-, dust- and vandal-proof housing (IP 65)

scope

• Outdoor antennas for Fixed Wireless Access (FWA)
• LTE/5G internet connections for consumers
• Industrial and commercial LTE/5G implementations
• Improving reception in urban households
• Telemetry access for electricity, energy and water
• Communication systems for oil and gas
• Municipal and state systems
• Repeaters and amplifiers to improve coverage

Technical data

• New 3400 to 3800MHz, 5G band
• Broadband, including the latest 3.5GHz bands
• X-polarized 2x2 or 4X4 MIMO antenna
• Wall or mast mounting possible
• Light and robust
• Weatherproof (IP65)
• High pattern consistency across bands for 4G/5G carrier aggregation
• Coax cable type: HDF-195
• Coax cable length: 5 meters
• Connection Type: SMA - Male
• Wind survival time: ≤250 km/h *Except for window mounting configuration
• Temperature range (operation): -40°C to +70°C
• Environmental conditions: Outdoor/Indoor
• Protection class/standard for water ingress: IP 65
• Salt spray: MIL-STD 810G/ASTM B117
• Relative humidity during operation: Up to 98%
• Storage humidity: 5% to 95% - non-condensing
• Storage temperature: -40°C to +70°C
• Housing flammability rating: UL 94-HB
• Impact resistance: IK 10
• Product dimensions 247mm x 157mm x 88mm
• Packaging dimensions:
• 270 mm x 190 mm x 100 mm
• Radome material: UV-stable ASA
• Radome color: Brilliant White Pantone P 179-1 C
• Mounting type: wall, mast and window mounting
