Ajax FireHub – The Central Unit of the New Wireless Fire Alarm System

The Ajax FireHub is the core of the new wireless fire alarm system from Ajax Systems.
It was specifically developed for professional fire warning installations certified under the European EN 54 standards.
As the central control unit, it connects all detectors, sirens, and control devices within the system, ensuring reliable, secure, and flexible fire monitoring – ideal for commercial buildings, hotels, schools, or larger residential complexes.

⚙️ Technical Features at a Glance

Certifications

Complies with EN 54-2, EN 54-4, EN 54-13, EN 54-21, and EN 54-25, fulfilling all requirements for use in certified fire warning systems.

Communication & Range

Using the proprietary Jeweller radio protocol, the wireless connection achieves a range of up to 1,800 meters in open space.
Additionally, the FireHub communicates via Ethernet, Wi-Fi, or mobile networks (2G/3G/LTE).
This ensures uninterrupted operation and accessibility, even during power or network outages.

Capacity & Expansion

The FireHub supports up to 200 wireless devices – including smoke detectors, temperature sensors, CO detectors, sirens, and expansion modules – as well as 40 configurable fire zones.
This scalability makes it suitable for buildings of all sizes.

Power Supply

In addition to mains power, the FireHub includes an integrated backup battery, providing 24 to 72 hours of autonomous operation during a power failure.

Display & Operation

A built-in 10-inch touchscreen allows direct control of the entire system.
Its user-friendly interface offers intuitive navigation through zones, devices, events, and system notifications.

? Intelligent Features

Automatic System Monitoring

The FireHub continuously checks the status of all connected devices and immediately reports if a detector fails, a battery runs low, or a communication link is lost.

Real-Time Notifications

In the event of an alarm, fault, or maintenance requirement, the system sends push notifications, SMS messages, or calls to designated users or monitoring centers.
Through the Ajax mobile app, all events can be tracked in real time, complete with logs and status overviews.

Tamper Protection

Attempts to tamper with the device, open its housing, or disrupt communication are instantly detected and reported.
All data transmitted between the FireHub and its components is end-to-end encrypted, ensuring maximum cybersecurity.

Modular Design

The FireHub can be expanded with optional modules such as relays, output interfaces, or signaling units.
This modular structure makes it suitable for complex fire protection systems, including ventilation control, door release, or evacuation management.

? Integration & Remote Access

The Ajax FireHub can be fully managed via the Ajax PRO App and Ajax Cloud.
Installers and operators can monitor system status, assign devices, configure zones, set user permissions, and perform maintenance remotely — without needing to be on-site.
This simplifies maintenance and enables rapid response in case of an emergency.

? Installation & Maintenance

Installation is straightforward: simply connect the FireHub to power and the internet.
All wireless components are automatically detected and can be added within seconds using a QR code.
The system can then be tested, maintained, and fully documented — ideal for installers and certified professionals working under EN 54 compliance.

✅ Advantages of the Ajax FireHub

• Fully EN 54 certified for professional fire warning systems

• Wireless communication with long-range connectivity

• Multi-channel redundancy (Ethernet, Wi-Fi, mobile)

• Autonomous operation with built-in backup battery

• Centralized control via app and touchscreen

• Expandable – up to 200 devices and 40 zones

• Fast installation and easy maintenance

• Cloud and remote management capabilities

? Conclusion

The Ajax FireHub represents a new generation of fire control panels – wireless, intelligent, secure, and fully certified according to European standards.
It combines the reliability of traditional fire detection technology with the flexibility of modern wireless communication, making it ideal for buildings where conventional cabling would be too complex or expensive.

In combination with FireProtect and FireProtect Plus detectors, the Ajax FireHub provides a complete, scalable solution for modern fire safety – from single-family homes to large commercial and industrial properties.
